Operating principle

Countercurrent

Performance

Primary pressure(maximum)

300 bar (30 MPa)

Secondary pressure(static)

8.5 bar (0.85 MPa)

Secondary pressure at 130 dm3/ min

7.5 bar (0.75 MPa)

Hose length

Bail-out breathing hose

1060 mm

DPX hose

1030 mm

Relief valve

Release pressure

Ca 20 bar

Weight

1 kg
